Overview Package Size 320.00cm * 150.00cm * 170.00cm Package Gross Weight 5200.000kg Product DescriptionDesign speed : 1;
Overview
Working width : 140mm-1800mm
Flute profile : A.c.b.e.f avilable ,
Flooding system lubrication of the ruduction gear box , three axis gimbal transmission , isolated power supply , frequency converter control of the main unit .
Pneumatic contral guilding of paper provide perfect flute shape in high speed ,blast volum controllers is euipment .
The bearings of corrugated rolls and press rolls are lubricated by high temperature lubriation grease .
Auto-circulating glue feeding system is provided .
The corrugated roll is made of special alloy steel of 48 CrMo with grinding process and induction with hardnessof HRC56-60.
Surface of gluing roll is embossed with netting design and chrome plated . Hydraulic Mill Roll Stand
Maximum diameter : 1500mm
Wordking width : 1400mm-2500mm
Hydraulic control of the lifting and lowering , clamping and releasing ,right-left movement .
Pneumatic control of the web tension ,
Expand chuck or tooth chuck is optional .
Company Profile
Basic Info.
Model NO. | SF-280 |
Certification | ISO 9001:2000, ISO 9001:2008 |
Automation | Automatic |
Suitable for | Paper |
Paper Thickness | Normal Specification Paper |
Wdith | 1400mm-2500mm Optional |
Layers | 3 Layer ;5 Layer and 7 Layers |
Speed | 120-300 Meters Per Minute |
Transport Package | Container by Sea |
Trademark | Andy Machine |
Origin | Hebei |
HS Code | 84393000 |
Production Capacity | 10 Sets Per Year |
Packaging & Delivery
Package Size 320.00cm * 150.00cm * 170.00cm Package Gross Weight 5200.000kgProduct Description
Product DescriptionDesign speed : 120m/min ,Working width : 140mm-1800mm
Flute profile : A.c.b.e.f avilable ,
Flooding system lubrication of the ruduction gear box , three axis gimbal transmission , isolated power supply , frequency converter control of the main unit .
Pneumatic contral guilding of paper provide perfect flute shape in high speed ,blast volum controllers is euipment .
The bearings of corrugated rolls and press rolls are lubricated by high temperature lubriation grease .
Auto-circulating glue feeding system is provided .
The corrugated roll is made of special alloy steel of 48 CrMo with grinding process and induction with hardnessof HRC56-60.
Surface of gluing roll is embossed with netting design and chrome plated . Hydraulic Mill Roll Stand
Maximum diameter : 1500mm
Wordking width : 1400mm-2500mm
Hydraulic control of the lifting and lowering , clamping and releasing ,right-left movement .
Pneumatic control of the web tension ,
Expand chuck or tooth chuck is optional .
Model number | 1800 |
Weight | 5.2 tons |
Overall size | 3.2×1.5×1.7 |
Motor power | 7.5kw |
Delivery time | 60 days |
Loading port | Tianjin port |
